END PLATE 4149056 (2)

END PLATE 4149056 (2)

END PLATE 4149056 (2)

1 4149056

  • 4149056 - END PLATE
  • end

2 4149060

  • 4149060 - VALVE
  • valve - bucket
  • stabilizer & swing sections - Was 4149060B

3 4149058

  • 4149058 - VALVE
  • valve - boom crowd sections

4 4149057

  • 4149057 - PORT PLAT
  • port

5 17C6174

  • 17C6174 - BOLT

6 4E6

  • 4E6 - WASHER

7 6512606

  • 6512606 - 10 WASHER
  • W/Ref. 13 - Was 6510055

8 4149071

  • 4149071 - PLUNGER L
  • lift check

9 1550482

  • 1550482 - SPRING

10 4149069

  • 4149069 - BODY LIFT
  • lift check

11 6518998

  • 6518998 - ORFICE
  • swing section - .109" (2
  • 77 mm) dia.

12 6518043

  • 6518043 - PLUG
  • W/Ref. 13

13 743609

  • 743609 - RET RING
  • retainer

14 4149067

  • 4149067 - WASHER
  • S
  • shallow

15 4149068

  • 4149068 - SPRING SP
  • spool

16 4149072

  • 4149072 - WASHER
  • wire

17 4149070

  • 4149070 - WASHER
  • deep

18 6518052

  • 6518052 - VALVE
  • RELIEF
  • W/Ref. 13
  • 27 & 28

19 6515455

  • 6515455 - KIT
  • SEAL
  • between sections - Ref. 8-10

20 6510058

  • 6510058 - SEAL KIT
  • stabilizer swing section - Ref. 12
  • 17 & 27

21 6510059

  • 6510059 - REPAIR KT
  • boom or crowd sections - Ref. 12-14
  • 17
  • 18 & 27

22 5294158

  • 5294158 - SEAL KIT
  • relief valve - W/Ref. 13
  • 27 & 28 - Was 6515458

23 6515454

  • 6515454 - KIT
  • SEAL
  • major - Ref. 30-33
