SPIKE 6502468 (3)

SPIKE 6502468 (3)

SPIKE 6502468 (3)

1 6502468

  • 6502468 - SPIKE

2 1F420

  • 1F420 - CTTR PIN

3 6517955

  • 6517955 - PIN
  • HINGE

4 62D20

  • 62D20 - NUT

5 6517978

  • 6517978 - GUIDE

6 6518553

  • 6518553 - PAD
  • stabilizer - R.H.

7 6517954

  • 6517954 - PAD
  • stabilizer - L.H.

8 6517953

  • 6517953 - PIN

9 710822

  • 710822 - RING

10 6517982

  • 6517982 - PIN

11 6517983

  • 6517983 - PAD

12 4E6

  • 4E6 - WASHER

13 17C620

  • 17C620 - BOLT

14 6558504

  • 6558504 - HANDLE
  • grab

15 17C512

  • 17C512 - BOLT 5

16 6500774

  • 6500774 - SEAT
  • Also Order Ref. 54 (6560448 decal)

17 6660148

  • 6660148 - SLIDE LWR

18 17C516

  • 17C516 - BOLT

19 6532792

  • 6532792 - MOUNT
  • seat - Was 6592837

20 6558680

  • 6558680 - SPACER

21 14J3740

  • 14J3740 - PIN

22 6513963

  • 6513963 - GRIP HANDLE

23 6560270

  • 6560270 - WEDGE

24 83D8

  • 83D8 - LKNUT HEX FLG GR8

25 27E8

  • 27E8 - WASHER 10

26 6560283

  • 6560283 - MOUNT
  • R.H.

27 17C824

  • 17C824 - BOLT 5

28 6560585

  • 6560585 - SPACER

29 17C848

  • 17C848 - BOLT

30 6560602

  • 6560602 - SPRING

31 17C656

  • 17C656 - BOLT

32 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

33 17C612

  • 17C612 - SCREW HEX CAP

34 6546986

  • 6546986 - PIN

35 1F620

  • 1F620 - PIN COTTE

36 1318566

  • 1318566 - PIN

37 6502401

  • 6502401 - PIN

38 61D10

  • 61D10 - NUT

39 4E10

  • 4E10 - WASHER

40 17C1024

  • 17C1024 - BOLT

41 15C10104

  • 15C10104 - SCREW

42 6517979

  • 6517979 - COVER

43 6558039

  • 6558039 - TREAD
  • SAFETY

44 6558051

  • 6558051 - DECAL

45 6518997

  • 6518997 - HOUSING
  • upper

46 6560286

  • 6560286 - MOUNT
  • L.H.

47 6562638

  • 6562638 - COVER

48 31C508

  • 31C508 - BOLT

49 6596591

  • 6596591 - DECAL
  • warning - Was 6562925

50 6560448

  • 6560448 - DECAL
  • mtg. instr.

51 6560749

  • 6560749 - MOUNT KIT
  • mounting - Ref. 27-32 & 50
