PLATE, END 6510041 (4)
1 6510041
- 6510041 - PLATE
- END
- end
2 6513626
- 6513626 - VALVE
- SECTION
- valve - crowd
3 17C6174
- 17C6174 - BOLT
4 25E6
- 25E6 - WSHR
5 6512603
- 6512603 - VALVE
- RELIEF
6 6510063
- 6510063 - PLUG
7 4149070
- 4149070 - WASHER
- deep
8 4149072
- 4149072 - WASHER
9 6510048
- 6510048 - SPRING
10 4149067
- 4149067 - WASHER
- S
- shallow
11 947750
- 947750 - SCREW
12 58K110
- 58K110 - O RING 10
13 4149069
- 4149069 - BODY LIFT
- lift check
14 1550482
- 1550482 - SPRING
15 4149071
- 4149071 - PLUNGER L
- lift check
16 994793
- 994793 - POPPET
17 6510047
- 6510047 - SPRING
18 6598346
- 6598346 - PLUG ASSEMBLY
19 6598487
- 6598487 - ORIFICE
- .1085" (2
- 76 mm)
20 6598364
- 6598364 - ORIFICE
- .1875" (4
- 76 mm)
21 6598752
- 6598752 - ORIFICE
- .081" (2.06 mm) dia.
22 6598783
- 6598783 - PLUG
- W/Ref. 11 & 13
23 6598779
- 6598779 - SPRING
24 6598780
- 6598780 - POPPET US
- Was 6599494
25 6598782
- 6598782 - SEAT
26 6598781
- 6598781 - PLUNGER
27 6598778
- 6598778 - KIT
- SEAL
- stabilizer section - Ref. 11
- 13
- 14
- 16 & 39
28 6598203
- 6598203 - SEAL KIT
- complete overhaul
29 6510059
- 6510059 - REPAIR KT
- crowd section - Ref. 11
- 13
- 24
- 25
- 44 & 45
30 6510058
- 6510058 - SEAL KIT
- bucket & swing sections - Ref. 24
- 25
- 44 & 45
31 6598443
- 6598443 - SEAL KIT
- boom section - Ref. 11
- 13
- 14
- 16
- 24 & 25
32 6510064
- 6510064 - SEAL KIT
- between Section - Ref. 9
- 10
- 35 & 36
