SPIKE 6502468 (2)

SPIKE 6502468 (2)

SPIKE 6502468 (2)

1 6502468

  • 6502468 - SPIKE

2 1F420

  • 1F420 - CTTR PIN

3 6517955

  • 6517955 - PIN
  • HINGE

4 6517954

  • 6517954 - PAD
  • stabilizer - L.H.

5 6518553

  • 6518553 - PAD
  • stabilizer - R.H.

6 62D20

  • 62D20 - NUT

7 6517978

  • 6517978 - GUIDE
  • rack

8 6517953

  • 6517953 - PIN

9 710822

  • 710822 - RING

10 6517982

  • 6517982 - PIN

11 6517983

  • 6517983 - PAD

12 4E6

  • 4E6 - WASHER

13 17C620

  • 17C620 - BOLT

14 6517981

  • 6517981 - FT REST R
  • foot

15 84G3112

  • 84G3112 - SCREW THD ROLLING TT
  • Was 14G-512

16 6504729

  • 6504729 - BRACKET

17 6515499

  • 6515499 - PIN
  • safety

18 6500774

  • 6500774 - SEAT

19 1F416

  • 1F416 - PIN
  • Was 1F-412

20 25E18

  • 25E18 - WASHER FLAT PLAIN

21 6504391

  • 6504391 - PIN

22 6540283

  • 6540283 - PLATE

23 17C716

  • 17C716 - BOLT

24 4E7

  • 4E7 - WASHER

25 6540286

  • 6540286 - BRACE

26 17C624

  • 17C624 - BOLT 5

27 6540287

  • 6540287 - BRACE

28 6540288

  • 6540288 - BRACE

29 6517979

  • 6517979 - COVER

30 4E10

  • 4E10 - WASHER

31 61D10

  • 61D10 - NUT

32 6502401

  • 6502401 - PIN

33 17C512

  • 17C512 - BOLT 5

34 61D6

  • 61D6 - NUT HEX FINISHED GR5

35 6513633

  • 6513633 - PIN

36 61D12

  • 61D12 - NUT

37 23E12

  • 23E12 - WASHER
  • Was 4E12

38 17C1244

  • 17C1244 - BOLT

39 15C10104

  • 15C10104 - SCREW

40 17C1024

  • 17C1024 - BOLT

41 6546983

  • 6546983 - FRAME
  • bob-tach mounted

42 6502400

  • 6502400 - HOOK
  • mounting - weld on

43 6557836

  • 6557836 - RIVET

44 6518997

  • 6518997 - HOUSING
  • upper bearing - weld on

45 6546986

  • 6546986 - PIN

46 1F632

  • 1F632 - PIN

47 6558039

  • 6558039 - TREAD
  • SAFETY

48 6502750

  • 6502750 - DECAL
  • WARNING
  • caution

49 6552174

  • 6552174 - DECAL
  • mounting instructions

50 6596591

  • 6596591 - DECAL
  • warning - Was 6562925
