END PLATE 4149056 (1)

END PLATE 4149056 (1)

END PLATE 4149056 (1)

1 4149056

  • 4149056 - END PLATE
  • end

2 4149060

  • 4149060 - VALVE
  • valve - bucket
  • stabilizer & swing sections - Was 4149060B

3 4149058

  • 4149058 - VALVE
  • valve - boom & dipperstick sections

4 4149057

  • 4149057 - PORT PLAT
  • port

5 17C6174

  • 17C6174 - BOLT
  • section retaining

6 4E6

  • 4E6 - WASHER

7 4149071

  • 4149071 - PLUNGER L
  • lift check

8 1550482

  • 1550482 - SPRING

9 4149069

  • 4149069 - BODY LIFT
  • lift check

10 6518998

  • 6518998 - ORFICE
  • upper swing section

11 6518043

  • 6518043 - PLUG
  • W/Ref. 13

12 743609

  • 743609 - RET RING
  • retainer

13 4149067

  • 4149067 - WASHER
  • S
  • shallow

14 4149068

  • 4149068 - SPRING SP
  • spool

15 4149072

  • 4149072 - WASHER
  • wire

16 4149070

  • 4149070 - WASHER
  • deep

17 6518052

  • 6518052 - VALVE
  • RELIEF
  • W/Ref. 13
  • 27 & 28

18 6515455

  • 6515455 - KIT
  • SEAL
  • between sections - Ref. 8-10

19 6510058

  • 6510058 - SEAL KIT
  • stabilizer & swing sections - Ref. 12
  • 17 & 27

20 6510059

  • 6510059 - REPAIR KT
  • boom or crowd sections - Ref. 12
  • 14
  • 17
  • 18 & 27

21 5294158

  • 5294158 - SEAL KIT
  • relief valve - Ref. 13
  • 14
  • 27 & 28

22 6515454

  • 6515454 - KIT
  • SEAL
  • major - Ref. 6515455
  • 6510058
  • 6510059 & 5294158B
