VALVE, RELIEF 6512603

VALVE, RELIEF 6512603

VALVE, RELIEF 6512603

1 6512603

  • 6512603 - VALVE
  • RELIEF
  • 2750 PSI - not included in valve section

2 6632473

  • 6632473 - PLUG
  • lift check - Was 947754B

3 1550482

  • 1550482 - SPRING
  • lift check

4 4149071

  • 4149071 - PLUNGER L
  • lift check

5 6519735

  • 6519735 - WASHER
  • deep

6 4149068

  • 4149068 - SPRING SP
  • spool

7 6510054

  • 6510054 - WASHER

8 4149067

  • 4149067 - WASHER
  • S
  • shallow

9 6510052

  • 6510052 - BLOCK
  • detent

10 73G416

  • 73G416 - SCREW
  • cap - Was 11G000416B

11 6519736

  • 6519736 - PLUG
  • detent pawl

12 6510053

  • 6510053 - SPRING
  • detent pawl

13 6510050

  • 6510050 - PAWL
  • detent

14 4149069

  • 4149069 - BODY LIFT
  • lift check

15 6511196

  • 6511196 - ORIFICE
  • .1875 - not included in valve section

16 6510064

  • 6510064 - SEAL KIT
  • between sections - Ref. 11-13

17 6510060

  • 6510060 - SEAL KIT
  • Ref. 3
  • 4
  • 6
  • 8
  • 14
  • 27 & 28
