SPIKE 6502468 (1)

SPIKE 6502468 (1)

SPIKE 6502468 (1)

1 6502468

  • 6502468 - SPIKE

2 1F420

  • 1F420 - CTTR PIN

3 6517955

  • 6517955 - PIN
  • HINGE

4 6517954

  • 6517954 - PAD
  • stabilizer - L.H.

5 6518553

  • 6518553 - PAD
  • stabilizer - R.H.

6 62D20

  • 62D20 - NUT

7 6517978

  • 6517978 - GUIDE
  • rack

8 6517953

  • 6517953 - PIN

9 710822

  • 710822 - RING

10 6517982

  • 6517982 - PIN

11 6517983

  • 6517983 - PAD

12 4E6

  • 4E6 - WASHER

13 17C620

  • 17C620 - BOLT

14 6517981

  • 6517981 - FT REST R
  • foot

15 84G3112

  • 84G3112 - SCREW THD ROLLING TT
  • Was 14G-512

16 6504729

  • 6504729 - BRACKET

17 6515499

  • 6515499 - PIN
  • safety

18 17C612

  • 17C612 - SCREW HEX CAP

19 61D6

  • 61D6 - NUT HEX FINISHED GR5

20 6502412

  • 6502412 - BRACKET

21 17C716

  • 17C716 - BOLT

22 4E7

  • 4E7 - WASHER

23 6502410

  • 6502410 - BRACE
  • R.H.

24 6502411

  • 6502411 - BRACE
  • L.H.

25 6502401

  • 6502401 - PIN

26 6517979

  • 6517979 - COVER

27 4E10

  • 4E10 - WASHER

28 61D10

  • 61D10 - NUT

29 6513633

  • 6513633 - PIN
  • W/cable

30 61D12

  • 61D12 - NUT

31 23E12

  • 23E12 - WASHER
  • Was 4E12

32 17C1244

  • 17C1244 - BOLT

33 15C10104

  • 15C10104 - SCREW

34 17C1024

  • 17C1024 - BOLT

35 6502400

  • 6502400 - HOOK
  • mounting - weld on

36 6558039

  • 6558039 - TREAD
  • SAFETY

37 6557836

  • 6557836 - RIVET

38 6502750

  • 6502750 - DECAL
  • WARNING
  • caution

39 6518997

  • 6518997 - HOUSING
  • bearing - weld on
