GAUGE LEVEL 7003868

GAUGE LEVEL 7003868

GAUGE LEVEL 7003868

1 7003868

  • 7003868 - GAUGE LEVEL

2 7005889

  • 7005889 - FILTER SUCTION
  • W/Ref. 3

3 7004866

  • 7004866 - FILTER STRAINER SUCTION

4 7004999

  • 7004999 - COVER TANK

5 7005652

  • 7005652 - BOLT M10X1.5X22

6 7276396

  • 7276396 - FILTER
  • BREATHER AIR
  • W/Ref. 7 & 8

7 7006806

  • 7006806 - FILTER
  • AIR BREATHER
  • Use W/Ref. 6 (NLA/ 7006509 filter assy)

8 7276395

  • 7276395 - ELEMENT
  • FILTER
  • Use W/Ref. 6 (7276396 filter assy)

9 7006946

  • 7006946 - GASKET

10 7007835

  • 7007835 - WASHER SPRING

11 7322931

  • 7322931 - COVER TANK

12 7276394

  • 7276394 - VALVE
  • BYPASS

13 7004883

  • 7004883 - FILTER RETURN

14 7004594

  • 7004594 - SPRING

15 7005875

  • 7005875 - TUBELINE SUCTION

16 7004635

  • 7004635 - O-RING

17 7007669

  • 7007669 - BOLT
  • Was 7007668

18 7004733

  • 7004733 - PLUG

19 7007916

  • 7007916 - O-RING

20 7007640

  • 7007640 - BOLT

21 7004473

  • 7004473 - WASHER M12

22 7007836

  • 7007836 - WASHER SPRING M12

23 7007950

  • 7007950 - O-RING

24 7004545

  • 7004545 - BOLT

25 7004504

  • 7004504 - SHIM
  • 1.0T
  • 1
  • 0 mm

26 7004505

  • 7004505 - SHIM
  • 0.6T
  • 0
  • 6 mm

27 7004506

  • 7004506 - SHIM

28 7276397

  • 7276397 - TANK
  • OIL
