LAMP ROOM 7005022

LAMP ROOM 7005022

LAMP ROOM 7005022

1 7005022

  • 7005022 - LAMP ROOM
  • W/Ref. 2

2 7004887

  • 7004887 - LIGHT BULB 12V/10W

3 7005684

  • 7005684 - MOTOR WIPER

4 7024751

  • 7024751 - ARM
  • WIPER

5 7005003

  • 7005003 - BLADE WIPER

6 7005675

  • 7005675 - COVER

7 7024770

  • 7024770 - PAD
  • ROOF

8 7004908

  • 7004908 - SPEAKER

9 7277330

  • 7277330 - SPEAKER

10 7004970

  • 7004970 - NOZZLE WIPER MOTOR

11 7006145

  • 7006145 - PLATE

12 7004552

  • 7004552 - BOLT

13 7004516

  • 7004516 - WASHER

14 7005680

  • 7005680 - GROMMET

15 7005648

  • 7005648 - RIVET

16 7004535

  • 7004535 - BOLT

17 7007778

  • 7007778 - BOLT

18 7007810

  • 7007810 - WASHER

19 7004858

  • 7004858 - ADAPTER
