KIT PIVOT BOB-TACH 7302293

KIT PIVOT BOB-TACH 7302293

KIT PIVOT BOB-TACH 7302293

1 7302293

  • 7302293 - KIT PIVOT BOB-TACH
  • Ref. 10 (7255136 screw)
  • 13 (7252989 pivot) & 14 (7277777 pin)

2 7172328

  • 7172328 - DECAL
  • Backhoe use

3 6561383

  • 6561383 - DECAL
  • OPERATION 5
  • Bob-Tach locking levers

4 6705340

  • 6705340 - DECAL
  • GREASE

5 7163435

  • 7163435 - LEVER
  • BOB-TACH
  • LH

6 7163436

  • 7163436 - LEVER
  • BOB-TACH
  • RH

7 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

8 619021

  • 619021 - WASHER

9 6704453

  • 6704453 - SPRING COMPRESSION

10 7255136

  • 7255136 - SCREW
  • SOCKET HEAD
  • 28
  • 58 mm (1.125") long - Use W/Ref. 13 (7252989 pivot)

11 6728473

  • 6728473 - BOLT
  • SHOULDER
  • 57
  • 15 mm (2.25") shoulder - pre-applied thread locker - Use W/Ref. 13 (6704248 pivot)

12 6704240

  • 6704240 - PIVOT
  • WEDGE

13 6578253

  • 6578253 - SPRING
  • COMPRESSION

14 7252989

  • 7252989 - PIVOT
  • WEDGE
  • 156 mm (6.15") long - Use W/Ref. 10 (7255136 screw)

15 6704248

  • 6704248 - PIVOT
  • WEDGE

16 7277777

  • 7277777 - PIN
  • Was 14J5032

17 6737191

  • 6737191 - WEDGE
  • BOB-TACH

18 17C644

  • 17C644 - BOLT

19 10H35

  • 10H35 - FTG GREASE STRAIGHT

20 6555341

  • 6555341 - TREAD
  • SAFETY

21 6987315ENUS

  • 6987315ENUS - INSTRUCTIONS
  • Was 6987315
