BOLT 947743 (2)
1 947743
- 947743 - BOLT
2 4E6
- 4E6 - WASHER
3 25K20104
- 25K20104 - O RING 10
4 58K024
- 58K024 - O-RING 10
5 58K28
- 58K28 - O RING 10
6 25K30016
- 25K30016 - O RING 10
7 6632473
- 6632473 - PLUG
- W/Ref. 7 - Was 947754B
8 947719
- 947719 - PLUNGER
9 947737
- 947737 - SPRING
10 25K30028
- 25K30028 - O RING 10
11 947759
- 947759 - PLUG
- W/Ref. 11
12 947753
- 947753 - PLUG
- W/Ref. 14
13 25K30030
- 25K30030 - O RING 10
14 947717
- 947717 - PLUNGER
15 25K40024
- 25K40024 - O RING 10
16 6665480
- 6665480 - VALVE
- RELIEF
- W/Ref. 19 - Was 6664959
17 25K30018
- 25K30018 - O RING 10
18 25K30024
- 25K30024 - O RING 10
19 947745
- 947745 - RETAINER
20 947748
- 947748 - WASHER
21 947738
- 947738 - SPRING
22 947749
- 947749 - WASHER
23 947711
- 947711 - CAP ASSY
24 6631988
- 6631988 - BOLT
25 948310
- 948310 - KIT
- boom section - Ref. 11
- 14
- 16-19
- 22
- 23 & 26
26 948311
- 948311 - KIT
- SEAL
- between sections - Ref. 4-6 - one kit per valve bank
27 6657100
- 6657100 - SEAL KIT
- W/Ref. 17-19 - Use W/Ref. 20 W/ 32041LA marked on end of relief valve
28 6669653
- 6669653 - SEAL KIT
- W/Ref. 17-19 - Use W/Ref. 20 W/ 32041LA or 32041LA3 marked on end of relief valve
