U BOLT 799674 (2)

U BOLT 799674 (2)

U BOLT 799674 (2)

1 799674

  • 799674 - U BOLT

2 62D4

  • 62D4 - NUT HEX FINISHED GR5

3 4E4

  • 4E4 - WASHER

4 6508441

  • 6508441 - FLAT
  • control lever

5 1318565

  • 1318565 - PIN 5

6 6592805

  • 6592805 - ROD
  • extended steering

7 8D6

  • 8D6 - NUT HEX JAM

8 6500774

  • 6500774 - SEAT

9 6660148

  • 6660148 - SLIDE LWR

10 6542128

  • 6542128 - SEATRISER
  • seat

11 658455

  • 658455 - ROLL PIN

12 17C512

  • 17C512 - BOLT 5

13 2J6208

  • 2J6208 - YOKE
  • adjustable

14 6593351

  • 6593351 - DECAL
  • mounting instructions

15 663350

  • 663350 - PIN
  • hinge

16 61D8

  • 61D8 - NUT 5

17 4E8

  • 4E8 - WASHER

18 25E21

  • 25E21 - WASHER FLAT PLAIN

19 6592803

  • 6592803 - LEVER
  • auxiliary steering

20 6508444

  • 6508444 - BUSHING

21 17C614

  • 17C614 - BOLT

22 6542125

  • 6542125 - GUARD
  • hand controls

23 18C844

  • 18C844 - BOLT

24 61D6

  • 61D6 - NUT HEX FINISHED GR5

25 784469

  • 784469 - WASHER

26 1F316

  • 1F316 - PIN

27 6542124

  • 6542124 - PIN
  • hinge

28 6542286

  • 6542286 - BAR

29 17C628

  • 17C628 - BOLT

30 17C820

  • 17C820 - BOLT 5

31 6542802

  • 6542802 - SCREEN

32 17C652

  • 17C652 - BOLT

33 947670

  • 947670 - PIN
  • hinge

34 81D6

  • 81D6 - NUT

35 6508367

  • 6508367 - SHIELD

36 6508540

  • 6508540 - CYLINDER
  • stabilizer

37 6508372

  • 6508372 - COLLAR
  • locking

38 6508370

  • 6508370 - PIN
  • hinge

39 18C824

  • 18C824 - BOLT

40 6515823

  • 6515823 - SPADE
  • stabilizer

41 62D8

  • 62D8 - NUT

42 6508545

  • 6508545 - LEG
  • stabilizer - W/Ref. 44 & 45

43 6508233

  • 6508233 - BUSHING

44 10H35

  • 10H35 - FTG GREASE STRAIGHT

45 18C872

  • 18C872 - SCREW

46 947669

  • 947669 - PIN
  • hinge

47 18C648

  • 18C648 - BOLT

48 82D6

  • 82D6 - NUT

49 6506175

  • 6506175 - DECAL
  • control levers

50 6506176

  • 6506176 - DECAL
  • control levers

51 6542071

  • 6542071 - FRAME
  • main assy.

52 6563138

  • 6563138 - DECAL
  • WARNING
  • warning

53 6596591

  • 6596591 - DECAL
  • warning - Was 6562925

54 25E17

  • 25E17 - WASHER FLAT PLAIN

55 6727324

  • 6727324 - DECAL
  • LOGO BOBCAT AND HEAD
  • Was 6569071
