NUT HEX FINISHED GR5 62D6 (5)

NUT HEX FINISHED GR5 62D6 (5)

NUT HEX FINISHED GR5 62D6 (5)

1 62D6

  • 62D6 - NUT HEX FINISHED GR5

2 61D5

  • 61D5 - NUT HEX FINISHED GR5

3 6651867

  • 6651867 - VALVE
  • RELIEF

4 6646687

  • 6646687 - SPOOL SEC
  • Swing & Stab. - W/Ref. 6
  • 7
  • 9-12
  • 15
  • 16
  • 21-25

5 6646691

  • 6646691 - O-RING

6 6646689

  • 6646689 - SECT.SPOL
  • Bucket & Dipper - W/O Ref. 13
  • 14 - W/Ref. 6
  • 7
  • 9-12
  • 15
  • 16
  • 21-25

7 948016

  • 948016 - PLATE

8 6646679

  • 6646679 - VALVE
  • RELIEF

9 961240

  • 961240 - O-RING

10 6630965

  • 6630965 - POPPET

11 6630966

  • 6630966 - SPRING

12 6646701

  • 6646701 - VALVE
  • RELIEF

13 6514392

  • 6514392 - TIE BOLT
  • Tie

14 6514391

  • 6514391 - TIE BOLT
  • Tie

15 6651873

  • 6651873 - SECTION
  • End

16 948017

  • 948017 - SEAT
  • Spring

17 948018

  • 948018 - SPRING

18 948191

  • 948191 - CAPSCREW

19 948192

  • 948192 - CAP

20 73G412

  • 73G412 - SCREW

21 6646695

  • 6646695 - SEAL KIT
  • O-Rings & Back-Up Rings for Ref. 13 & 17

22 6646698

  • 6646698 - SEAL KIT
  • Spool - W/Ref. 6
  • 9 & 10

23 6652870

  • 6652870 - SEAL KIT
  • Ref. 7
  • 20
  • 26 & 30 - Complete - Includes Ref. 26 & 27
