O RING 10 79K12 (3)

O RING 10 79K12 (3)

O RING 10 79K12 (3)

1 79K12

  • 79K12 - O RING 10
  • Was 91F000008B

2 15KB1012

  • 15KB1012 - FTG HYD S CONNECTOR
  • W/Ref. 1 - Was 755055B

3 6542236

  • 6542236 - ASSY
  • HOSE

4 17C624

  • 17C624 - BOLT 5

5 8D14

  • 8D14 - NUT

6 61D6

  • 61D6 - NUT HEX FINISHED GR5

7 6515813

  • 6515813 - BAR

8 6515832

  • 6515832 - TUBE
  • right bucket cylinder

9 6515833

  • 6515833 - TUBE
  • left bucket cylinder

10 6542234

  • 6542234 - HOSE

11 17C516

  • 17C516 - BOLT

12 4E4

  • 4E4 - WASHER

13 6515885

  • 6515885 - PART

14 947695

  • 947695 - ORIFICE
  • boom return port

15 6542235

  • 6542235 - ASSY
  • HOSE

16 15K7

  • 15K7 - FITTING
  • W/Ref. 17

17 79K10

  • 79K10 - O RING 10
  • Was 91F000007B

18 6508537

  • 6508537 - CYLINDER
  • boom

19 947589

  • 947589 - HOSE ASSY

20 6508539

  • 6508539 - CYLINDER
  • bucket

21 6508538

  • 6508538 - CYLINDER
  • dipperstick
