ELBOW 88F5 (1)
1 88F5
- 88F5 - ELBOW
2 14J3740
- 14J3740 - PIN
- Was 14J-1740
3 6713723
- 6713723 - HOSE
4 90F5
- 90F5 - TEE
5 6569861
- 6569861 - TOOTH
- GRAPPLE
6 6713735
- 6713735 - HOSE
7 85D6
- 85D6 - NUT PRETRQ HEX LOCK
8 6568476
- 6568476 - #12 CLAMP
9 6668115
- 6668115 - ORIFICE
- not used with later grapples - do not use with 6674688 coupler
10 7246777
- 7246777 - COUPLER
- FF MALE
- - straight - Was 6674688
11 7246777EF
- 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE
12 7246777
- 7246777 - COUPLER
- FF MALE
- - straight - Was 6674688
13 7246777EF
- 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE
14 7246790
- 7246790 - COUPLER FF FEM 1/2
- - straight - Was 6672960
15 7246790EF
- 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD
16 10H25
- 10H25 - FTG GREASE STRAIGHT
17 6567775
- 6567775 - TOOTH
18 6547593
- 6547593 - PIN
- PIVOT
- 4.3"
19 17C640
- 17C640 - BOLT
20 6547595
- 6547595 - PIN
21 6531433
- 6531433 - PIN
22 6588040
- 6588040 - SHIELD
- W/Weld-on Bushing
23 6727323
- 6727323 - DECAL
- LOGO BOBCAT AND HEAD
- LH - Was 6567987
24 6727324
- 6727324 - DECAL
- LOGO BOBCAT AND HEAD
- RH - Was 6567988
25 6630942
- 6630942 - HOSE
26 6588369
- 6588369 - EDGE
- CUTTING
27 86F5
- 86F5 - NUT
28 6569867
- 6569867 - MOUNT
- angle - weld on
29 6589193
- 6589193 - ELBOW
30 84G3708
- 84G3708 - SCREW
31 6713722
- 6713722 - COVER
- tubeline
32 6555987
- 6555987 - BUSHING
33 6555989
- 6555989 - BUSHING
34 6588044
- 6588044 - BUSHING
35 35C612
- 35C612 - SCREW FLGD HEX CAP
36 6900396
- 6900396 - INSTRUCTIONS
- mounting
37 6588042
- 6588042 - COVER
38 61D6
- 61D6 - NUT HEX FINISHED GR5
39 17C6104
- 17C6104 - BOLT
40 7D6
- 7D6 - NUT
41 6900519
- 6900519 - INSTRUCTIONS
42 6678574
- 6678574 - VALVE
- RELIEF
- Was 6599161
43 6678056
- 6678056 - ELBOW
- w/built-in .070" orifice
