O RING 10 79K8 (6)

O RING 10 79K8 (6)

O RING 10 79K8 (6)

1 79K8

  • 79K8 - O RING 10

2 15K6

  • 15K6 - ADAPTER
  • W/Ref. 1

3 12K6

  • 12K6 - UNION

4 18K6

  • 18K6 - FITTING
  • W/Ref. 1

5 6610510

  • 6610510 - STRAP
  • TIE 10
  • Was 1715312B

6 6624289

  • 6624289 - STRAP
  • TIE

7 6592852

  • 6592852 - ORIFICE
  • .191 - .183 (4
  • 85 - 4
  • 65mm) - Was 6592865

8 84G3110

  • 84G3110 - SCREW

9 6532644

  • 6532644 - HOSE

10 6532645

  • 6532645 - HOSE

11 6562267

  • 6562267 - CLAMP

12 30H46

  • 30H46 - CLIP

13 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

14 17C628

  • 17C628 - BOLT

15 6502426

  • 6502426 - CLAMP

16 17K6

  • 17K6 - ELBOW
  • W/Ref. 1

17 6562009

  • 6562009 - TUBE

18 6561915

  • 6561915 - TUBELINE

19 6561914

  • 6561914 - TUBE

20 6561913

  • 6561913 - TUBE

21 6532641

  • 6532641 - HOSE

22 6532642

  • 6532642 - HOSE

23 6532640

  • 6532640 - HOSE

24 6532639

  • 6532639 - HOSE

25 6562266

  • 6562266 - CLAMP TUBE

26 6651436

  • 6651436 - HOSE CVR.
  • 2.38'' (60
  • 45 mm) - I.D. bulk - sold per foot

27 6650108

  • 6650108 - SHIELD
  • 1.25' (31
  • 75 mm) - I.D. bulk - sold per foot

28 6649389

  • 6649389 - HOSE
  • CVR BULK/FT
  • 1'' (25
  • 4 mm) - I.D. bulk - sold per foot
