O RING 10 79K8 (3)

O RING 10 79K8 (3)

O RING 10 79K8 (3)

1 79K8

  • 79K8 - O RING 10

2 15K6

  • 15K6 - ADAPTER
  • W/Ref. 2

3 18K6

  • 18K6 - FITTING
  • W/Ref. 2

4 6610510

  • 6610510 - STRAP
  • TIE 10
  • Was 1715312B

5 6534635

  • 6534635 - HOSE

6 6533294

  • 6533294 - TUBE
  • Was 6532975

7 6587978

  • 6587978 - HOSE
  • Was 6533210

8 30H46

  • 30H46 - CLIP

9 6533292

  • 6533292 - TUBE
  • Was 6532974

10 6539420

  • 6539420 - HOSE
  • 17.50"(445mm) long

11 6704335

  • 6704335 - HOSE
  • 16.70"(424mm) long

12 6533293

  • 6533293 - TUBE
  • Was 6532973

13 84G3728

  • 84G3728 - SCREW THD ROLLING TT

14 6502426

  • 6502426 - CLAMP

15 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

16 6534685

  • 6534685 - HOSE

17 6649389

  • 6649389 - HOSE
  • CVR BULK/FT
  • 1"(25
  • 4mm) bulk - sold per foot

18 6592852

  • 6592852 - ORIFICE
  • .191 - .183 (4
  • 85 - 4
  • 65mm)

19 6704336

  • 6704336 - HOSE
  • Was 6539419

20 6586278

  • 6586278 - HOSE

21 6586279

  • 6586279 - HOSE

22 6591804

  • 6591804 - CLAMP

23 6537761

  • 6537761 - CLAMP

24 81D6

  • 81D6 - NUT
