O RING 10 79K8 (7)

O RING 10 79K8 (7)

O RING 10 79K8 (7)

1 79K8

  • 79K8 - O RING 10

2 15K6

  • 15K6 - ADAPTER
  • W/Ref. 2

3 12K6

  • 12K6 - UNION

4 18K6

  • 18K6 - FITTING
  • W/Ref. 2

5 6610510

  • 6610510 - STRAP
  • TIE 10
  • Was 1715312B

6 6534635

  • 6534635 - HOSE

7 6560366

  • 6560366 - TUBE

8 6533181

  • 6533181 - HOSE

9 17K6

  • 17K6 - ELBOW
  • W/Ref. 2

10 6560644

  • 6560644 - TUBE

11 6532194

  • 6532194 - HOSE
  • Was 6533183

12 6560365

  • 6560365 - TUBE

13 6560364

  • 6560364 - TUBE

14 84G3728

  • 84G3728 - SCREW THD ROLLING TT

15 6502426

  • 6502426 - CLAMP

16 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

17 6533182

  • 6533182 - HOSE

18 6649389

  • 6649389 - HOSE
  • CVR BULK/FT
  • 1'' (25
  • 4 mm) bulk - sold per foot

19 6592852

  • 6592852 - ORIFICE
  • .191 - .183 (4
  • 85 - 4
  • 65mm)

20 6650108

  • 6650108 - SHIELD
  • 1.25'' (31
  • 75 mm) sold per foot
