LCKNUT 61D16 (2)

LCKNUT 61D16 (2)

LCKNUT 61D16 (2)

1 61D16

  • 61D16 - LCKNUT
  • Was 61D000006B

2 6596558

  • 6596558 - PLATE
  • pivot

3 6596559

  • 6596559 - LINK ASSEMBLY
  • lockout - tilt

4 7246777EF

  • 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE

5 7246777

  • 7246777 - COUPLER
  • FF MALE
  • - straight - Was 6674688

6 6513634

  • 6513634 - COUPLER
  • male - poppet

7 6557920

  • 6557920 - PIN

8 6557887

  • 6557887 - PIN
  • threaded

9 6512159

  • 6512159 - COUPLER
  • female - poppet

10 7246790

  • 7246790 - COUPLER FF FEM 1/2
  • - straight - Was 6672960

11 58K211

  • 58K211 - O RING 10
  • Use with poppet coupler

12 7246790EF

  • 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD

13 6589193

  • 6589193 - ELBOW
  • Use with flush face couplers

14 1300059

  • 1300059 - ELBOW
  • Use with poppet couplers

15 31C1028

  • 31C1028 - BOLT 5

16 6649496

  • 6649496 - CLICK PIN
  • Was 6513692

17 53D10

  • 53D10 - NUT

18 6594048

  • 6594048 - PLATE
  • required when backhoe is used on 450 series
  • but must be removed for 553F - See Serviceletter of 2 April 1998

19 6594049

  • 6594049 - ANGLE
  • required when backhoe is used on 450 series
  • but must be removed for 553F - See Serviceletter of 2 April 1998

20 6566553

  • 6566553 - INSTRUCTIONS

21 6718710BR

  • 6718710BR - KIT
  • TRANSLATION
  • translation - SEE NOTE

22 6718710AR

  • 6718710AR - KIT
  • TRANSLATION
  • translation - SEE NOTE
