Bobcat
/
Backhoe
/
FITTING 36H25

FITTING 36H25

FITTING 36H25

1 36H25

  • 36H25 - FITTING

2 6544805

  • 6544805 - ROD CNTRL
  • control

3 6544828

  • 6544828 - LEVER
  • stabilizer - R.H.

4 6515888

  • 6515888 - KNOB

5 639991

  • 639991 - BUSHING

6 6544822

  • 6544822 - LEVER
  • R.H.

7 6544816

  • 6544816 - ASSY
  • LEVER
  • control - R.H.

8 6510093

  • 6510093 - KNOB

9 1F316

  • 1F316 - PIN

10 82D6

  • 82D6 - NUT

11 6544815

  • 6544815 - LEVER
  • control - L.H.

12 639991

  • 639991 - BUSHING

13 6544821

  • 6544821 - LEVER
  • L.H.

14 6544827

  • 6544827 - LEVER
  • stabilizer - L.H.

15 6560872

  • 6560872 - PIN

16 1F308

  • 1F308 - PIN
  • COTTER

17 6544835

  • 6544835 - CLEVIS

18 2J6208

  • 2J6208 - YOKE

19 4F6106

  • 4F6106 - PIN HARDENED CLEVIS

20 25E24

  • 25E24 - WASHER

21 1F316

  • 1F316 - PIN

22 6544831

  • 6544831 - BUSHING

23 6544702

  • 6544702 - ASSY
  • HOSE

24 7246777EF

  • 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE

25 7246777

  • 7246777 - COUPLER
  • FF MALE
  • - straight - Was 6674688

26 6598755

  • 6598755 - COUPLER
  • male - poppet

27 6515167

  • 6515167 - CAP
  • steel

28 6515168

  • 6515168 - CAP
  • steel

29 6513709

  • 6513709 - CAP AND PLUG
  • assy. - rubber

30 6596591

  • 6596591 - DECAL
  • warning - Was 6562925

31 25K40026

  • 25K40026 - O RING 10
  • Use with poppet coupler

32 7246790

  • 7246790 - COUPLER FF FEM 1/2
  • - straight - Was 6672960

33 6598756

  • 6598756 - COUPLER
  • female - poppet

34 7246790EF

  • 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD

35 1314990

  • 1314990 - BALL
  • ball

36 8D6

  • 8D6 - NUT HEX JAM

37 6544834

  • 6544834 - CLEVIS

38 6544698

  • 6544698 - ASSY
  • HOSE

39 6544697

  • 6544697 - ASSY
  • HOSE

40 6544703

  • 6544703 - ASSY
  • HOSE

41 6544699

  • 6544699 - ASSY
  • HOSE

42 6544806

  • 6544806 - MT ASSY
  • control

43 18K7

  • 18K7 - FITTING
  • W/Ref. 47

44 660758

  • 660758 - HYD HOSE

45 6553532

  • 6553532 - MAIN FRAME

46 6544696

  • 6544696 - HOSE

47 17C716

  • 17C716 - BOLT

48 4E7

  • 4E7 - WASHER

49 15G404

  • 15G404 - SCREW SET

50 6506176

  • 6506176 - DECAL
  • stabilizer

51 6506175

  • 6506175 - DECAL
  • operate

52 17C612

  • 17C612 - SCREW HEX CAP

53 79K10

  • 79K10 - O RING 10

54 6669284

  • 6669284 - ADAPTER
  • COUPLER
  • Use to convert to flush face couplers
